Description
Features
- Our portable Autoclaves are most ideal for doctors, nursing homes, laboratories, dentists, etc.
- Most ideal for general laboratory requirement where samples in small batches are required to be sterilized.
- Hydraulically tested up to 40psi for user safety.
- Spring-loaded safety valve for pressure adjustment and a dead weight valve works as a safety device.
- Economy at your fingertips with low power consumptions.
- A seamless (joint less) body for single-walled units provides a sturdy and safe operation for the user.
- Low sterilization process time accounts for a higher number of batches accounting for the economy and faster results.
- Body, lid & heater cover made of Single-Walled Stainless Steel (SS-304).
- Simple and easy “Press & turn” system of the closing lid for single-walled units.
- Lid is fitted with Pressure Gauge, Safety Valve, Manual Exhaust Valve.
- Vacuum breaker-cum-purge valve works as a safety device.
- Moulded neoprene rubber gasket.
- Fitted with Microprocessor Based SEMI AUTOMATIC DIGITAL TEMPERATURE INDICATOR-CUM-CONTROLLER
- Digital LED display for set value (SV) and process value (PV)
- Heater cover stand made of stainless steel (SS-304)
- Industrial grade energy efficient heaters reduce power bills drastically
Technical Specifications & Ordering Informations
| Model (CRC) | RBS AVF-28 (PROSAD-CRC) | RBS AVF-43 (PROSAD-CRC) | RBS AVF-64 (PROSAD-CRC) | RBS AVF-91 (PROSAD-CRC) | RBS AVF-135 (PROSAD-CRC) | RBS AVF-210 (PROSAD-CRC) |
|---|---|---|---|---|---|---|
| Model | RBS PAS-20(WN-SAD) | RBS PAS-27(WN-SAD) | ||||
| Inner Dimensions (Dia x Height) | 300x300mm | 300x375mm | ||||
| Gasket (Jointless) | Neoprene | Neoprene | ||||
| Capacity | 20 Ltrs | 27 Ltrs | ||||
| Heater Load | 2.0 KW | 2.0 KW | ||||
| Chamber Wall | Single | |||||
| Temp. Controller | Microprocessor Based SEMI AUTOMATIC DIGITAL TEMPERATURE INDICATOR-CUM-CONTROLLER | |||||
| Display | Digital LED display for set value (SV) and process value (PV) | |||||
| Exhaust of Pressure | Manually through a exhaust valve | |||||
| Pressure Gauge | 0-2.1 kgf/cm²(30 psi) | |||||
| Sterilizing Pressure | 0-2.1 kgf/cm² (15 psi) at 121°C | |||||
| MOC (Pressure Vessel) | Stainless Steel (SS-304) | |||||
| MOC (Top Lid) | Stainless Steel (SS-304) | |||||
| Power Supply | 220/230V AC, 50/60Hz | |||||
