STERILITY TEST UNIT “MAC” MSW-318
This is a small description
- Selection support
- Configuration guidance for your application
- Delivery
- Pan-India coordination from Mohali
- After-sales
- Installation, calibration and maintenance support
Product details
Features and construction
FEATURES
- Consists of S.S. holders in manifold of 3 or 6 holders for 47m.m. dia., membrane filters .
- The tops of the holders are connected to the outlets of the flushing tube with silicone tubing and glass stop cock.
- A vacuum resistant flask or woulfs bottle must be placed between the manifold and vacuum Pump. (Supplied without Woulf3.s Bottle and Vacuum/ Pressure Pump).
- These units are used for sterility testing when the membrane filter is to be removed from the holder for incubation in culture media.
- Filteration areas is 12.5 cm and has a holding capacity of 250ml. Though only vacuum is required for filleration, some pressure is required for flushing liquids.
- Made of Stainless Steel (SS-316)/PTFE and Autoclavable. Supplied complete with Manifold and filter holders.
Technical data
Specifications and models
| MODEL | MOC | FILTER DIA | MANIFOLD | HOLDING CAPACITY |
|---|---|---|---|---|
| #STU-3 | SS-316/PTFE (Autoclavable) | 47mm | Branch of 3 Test | 250 ml |
| #STU-6 | SS-316/PTFE (Autoclavable) | 47mm | Branch of 6 Test | 250 ml |
