STIRRER
LABORATORY OVERHEAD STIRRER "MAC" MSW-315(PRO)
This is a small description
- Selection support
- Configuration guidance for your application
- Delivery
- Pan-India coordination from Mohali
- After-sales
- Installation, calibration and maintenance support
Product details
Features and construction
Description
- Adjustable Speed Timing : Adjust the value with a knob. Convenient and efficient.
- Long press the knob –start.
- Short press the knob – switch the input station.
- Turn the knob to adjust the parameter value.
- Press the knob to stop during working.
- Wide range of uses : Brushless Motor, Strong torque, Strong Power Stirring. Suitable for liquids with different viscosity.
- Rated torque : 50N.cm & 100N.cm
- Maximum Viscosity : 35000mPas & 70000mPas
Options
- External temperature probe to cost extra. {Option available for #LOS-50(PRO) and #LOS-100(PRO) only}
Technical data
Specifications and models
| Model | Control | Motor Type | Speed | Stepping | Maximum Stirring Volume | Maximum Torque | Maximum Viscosity | Temperature Protection Display | Timing Range | Drill Clamp Diameter | Stirring Rod | Power | Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| #LOS-5(PRO) | Knob | Brushless Motor | 200 – 1500 rpm | 10 mm | 5 Ltrs. | 10N.cm | 5000mPas | No | 0 – 24 Hrs. | 1 – 10 mm | 1 Rod with different stirring leafs | 30 W | DC 24V 1.5A |
| #LOS-10(PRO) | Digital Display + Knob | Brushless Motor | 100 – 1500 rpm | 10 mm | 10 Ltrs. | 15N.cm | 8000mPas | No | 0 – 24 Hrs. | 1 – 10 mm | 1 Rod with different stirring leafs | 50 W | DC 24V 2.5A |
| #LOS-20(PRO) | Digital Display + Knob | Brushless Motor | 50 – 1200 rpm | 10 mm | 20 Ltrs. | 30N.cm | 16000mPas | No | 0 – 24 Hrs. | 1 – 10 mm | 1 Rod with different stirring leafs | 60 W | DC 24V 2.5A |
