STIRRER
MAGNETIC STIRRER WITHOUT HOT PLATE "MAC" MSW-313(PRO)
This is a small description
- Selection support
- Configuration guidance for your application
- Delivery
- Pan-India coordination from Mohali
- After-sales
- Installation, calibration and maintenance support
Product details
Features and construction
Description
- Concise and Compact Design : Concise and compact design, beautiful fashion, easy to receive and carry
- Infinitely Variable Speeds : Infinitely variable speeds, more convenient and practical
- Concise Panel Design : You could put the beaker on the centre point easily
- Usage : Magnetic Stirrers are often used in chemistry and biology, where they can be used inside hermetically closed vessels or systems, without the need for complicated rotary seals. They are preferred over gear driven motorized stirrers because they are quieter, more efficient and have no moving external parts to break or wear out.
Options
- External PT-100 sensor and clamping rod for measuring sample temperature
- PTFE coated magnetised stirrering paddle Size (Dia x Length) : 7 x 12 mm
- PTFE coated magnetised stirrering paddle Size (Dia x Length) : 7 x 15 mm
- PTFE coated magnetised stirrering paddle Size (Dia x Length) : 9 x 25 mm
- PTFE coated magnetised stirrering paddle Size (Dia x Length) : 9 x 35 mm
- PTFE coated magnetised stirrering paddle Size (Dia x Length) : 13 x 35 mm
- PTFE coated magnetised stirrering paddle Size (Dia x Length) : 13 x 50 mm
Technical data
Specifications and models
| Model | Control | Motor Type | Working Plate Size | Speed | Max Stirring Volume | Dimensions | Temperature Range | Stir Bar Size | Power | Shell Protection Level | Power Supply |
|---|---|---|---|---|---|---|---|---|---|---|---|
| #MS-1(PRO) | Rotary Knob | Brushless Motor | 125 mm | 350 - 1800 rpm | 1 L (H2O) | 138 x 130 x 41 mm | Ambient 5°C ~ 40°C 80% RH | 30 mm | 3 W | IP42 | 220 / 230V, 50/60 Hz |
| #MS-2(PRO) | Rotary Knob | Brushless Motor | 135 mm | 350 - 1800 rpm | 2 L (H2O) | 168 x 160 x 47 mm | Ambient 5°C ~ 40°C 80% RH | 30 mm | 5 W | IP42 | A220 / 230V, 50/60 Hz |
| #MS-2D(PRO) | Rotary Knob / LCD Display | Brushless Motor | 135 mm | 200 - 2000 rpm | 2 L (H2O) | 168 x 160 x 47 mm | Ambient 5°C ~ 40°C 80% RH | 30 mm | 5 W | IP42 | 220 / 230V, 50/60 Hz |
| #MS-5(PRO) | Rotary Knob / LCD Display | Brushless Motor | 135 mm | 50 - 1500 rpm | 5 L (H2O) | 168 x 160 x 47 mm | Ambient 5°C ~ 40°C 80% RH | 20 - 30 mm | 5 W | IP42 | A220 / 230V, 50/60 Hz |
