Features
RANBIOSOL Semi Automatic Digital Autoclaves are most ideal for critical applications requiring assured and reliable total destruction of all living micro-organisms.
These are semi automatic models requiring tighter control of temperature and sterilizing time, thus eliminating any chances of under or over exposure of media/ samples with respect to temperature and hold time.
Inner chamber is made of Stainless Steel (SS-304 grade).
Outer body is made of Stainless Steel.
Heaters cover stand and carrier/bucket are made of Stainless Steel.
Lid made of thick machined Stainless Steel plate.
Radial locking lid ensures user safety and safe locking.
Radial arms are made of mild steel.
Legs are made of mild steel.
Rings & legs are made of mild steel.
Lid is fitted with Pressure Gauge, Spring Loaded Safety Valve, extra Safety Valve, Manual Exhaust Valve, Vacuum Breaker-cum-Purge Valve as a safety device and water level indicator.
Drain Valve facilitates easy cleaning of the chamber.
Moulded jointless silicon rubber gasket.
All internal joints are argon arc welded, ground and polished to give crevice free internals.
µProcessor based Controller with time and temperature settable by user.
Operating range from 15 to 22 psi pressure. (adjustable)
Class ‘A’ Platinum (Pt-100) sensor, enabling precise and accurate monitoring in 0.1°C resolution and ±1°C accuracy.
End of cycle buzzer to alert the user.
Miniature Circuit Breaker for MAINS On/Off plus safety of control panel.
Industrial grade energy efficient heaters reduce power bills drastically.
Fitted with low water cut-off for general safety of heating elements.
To work on 220/230Volts, 50/60 Hz AC supply.
Technical Specifications
Technical Specifications & Ordering Informations
Model
RBS AVS-28(EX)
RBS AVS-43(EX)
RBS AVS-64(EX)
RBS AVS-91(EX)
RBS AVS-135(EX)
RBS AVS-210(EX)
Inner Dimensions (Dia x Height)
Ø250x450mm
Ø300x500mm
Ø350x550mm
Ø400x600mm
Ø450x710mm
Ø550x760mm
Capacity
28/22 Ltrs.
43/40 Ltrs.
64/53 Ltrs.
91/78 Ltrs.
135/113 Ltrs.
210/187 Ltrs.
Heater Load
2.0 KW
3.0 KW
3.0 KW
4.0 KW
4.0 KW
5.0 KW
Gasket
Made of Jointless Silicon Rubber
Controller
Semi Automatic Digital temperature Indicator-cum-Controller
Display
Digital LED with Set Value (SV) and Process Value (PV)
Timer (Auto Time Control) & Buzzer
Fitted with AUTOMATIC DIGITAL MINUTE TIMER which starts automatically when set/desired value of temperature is achieved.
When the set time period is over the heaters get switched off automatically
Buzzer
Alarm for cycle end
Sterilizing Pressure
1.2 kgf /cm2 (15 psi) at 121°C
Operating Pressure
From 15psi to 22 psi (Adjustable)
MOC (Pressure Vessel)
Stainless Steel (SS-304)
MOC (External Wall)
Stainless Steel
MOC (Top Lid)
Thick machined Stainless Steel plate
Basket
Stainless Steel (SS-304)
Exhaust Supply
Manually through a exhaust valve
Power Supply
220/230V AC, 50/60Hz
